PDF Drawing Conversion to MicroStation Format for a Canadian Company

The Customer

The customer is a renowned engineering consultancy provider based in Canada, and got in touch with the team at Outsource2india. Our customer's primary work involves advising and assisting top Energy and Automation companies with technical project management.

The Requirement

The customer wanted to proceed with 2D to 3D conversion for several files. The client also wanted their PDF files to be specifically converted into 3D MicroStation files, on the MicroStation software, Version 8. Earlier on, the customer had already outsourced this requirement to other CAD service providers, but they were unable to receive an accurate solution that met their specifications; finally he approached Outsource2india's team hoping for a winning solution.

The Challenge

The customer had pre-defined standards that were challenging for our team to adhere to. Some of the standards that our team had to maintain while converting the customer's PDF files were as follows:

  • Colors
  • Line weight
  • Line scale
  • Text size
  • Text adjusting
  • Font style
  • Font size, etc

The Solution

The team at Outsource2india presented the customer with a winning solution that met the exact specifications of the customer. Excerpts of our solution are as follows:

  • Accurate redrawing of the file by using the same legend
  • Precise drawings as per the customer's expectations
  • Importing of the files via SmartPlant®

The Results

Our team was able to successfully complete the project on time and our quality surpassed the expectations of the customer. We were able to:

  • Deliver the completed project as per the customer's deadline specified in the SLA (2 weeks)
  • Present the customer with an unmatched quality level of 100%
  • Provide the client with rewriting solutions that guaranteed customer satisfaction

Needless to say, client awarded us with other similar projects, and regularly works with us.

Are you also looking for a similar business solution? If yes, we at Outsource2india can assist you with expert 2D to 3D conversion that is accurate, precise and fast. Get in touch with us right away and leverage the many benefits that only outsourcing can offer.
