Plant Design Management System

The plant engineering and design industry is gradually evolving and incorporating the latest technological advancements in planning, designing, modifying, installing and maintaining various plant facilities, systems, equipment etc. PDMS services are especially useful while designing mechanical, structural, instrumental, and piping designs.

At Outsource2india, we believe that efficient plant design is a stepping stone towards increased productivity, lesser bottlenecks, ability to manufacture different products concurrently, and overall business expansion.

Our plant design management system team is comprised of experienced engineers, senior designers, draftsmen and managers, allowing us to provide our clients with ideal, cost-effective solutions within the required turnaround time.

Our Service Portfolio - Plant Design Management System

Our extensive PDMS portfolio is a testament to our dedication for providing exemplary plant engineering services. Our team of engineers has logged a sum total of more than 25,000 hours working with our clients, and our strict accordance to ISO 9001 standards ensures optimal quality of the final deliverable.

At O2I, we are well-versed with EPA, NFPA, OSHA, UBC and other standard regulatory codes, ensuring that our services are not only in accordance with various rules, but also of the highest quality possible. Our team of designers and engineers can skillfully develop necessary equipment specifications, plant designs etc., and offer you flexible execution strategies including on-site as well as off-site team for personalized attention.

We offer our services for a variety of industry verticals such as Piping, Civil & Structural, Electrical & Instrumentation, and Industrial Equipment etc. Our offering for efficient plant design management system includes -

  1. Pre-bid Proposal Engineering

    We are domain experts in providing effective pre-bid engineering proposals, and have assisted numerous global clients and contractors during the pre-bid process by performing the following essential activities , though not limited to -

    • Designing initial conceptual designs in accordance to bid parameters
    • Providing engineering estimates
    • Estimating the bill of quantities
    • Collecting necessary data directly from the site if required
  2. Bid Evaluation Assistance

    Over the years, we have provided exemplary bid evaluation assistance to our clients by providing an in-depth technical analysis of the bids received. Our analysis considers several factors to corroborate the legitimacy of the bid such as price of materials and products, personnel skills and qualification, prior projects handled by the bidder etc. By evaluating the bids carefully, we help our clients save money and time, and focus on other important project related work

  3. Detailed Engineering

    Before embarking on the piping and plant construction project, we assist our clients in performing a variety of detailed engineering studies to extract the necessary information from basic engineering drawings and project calculations. Our detailed engineering services consists of the following -

    • MTO (BOM)
    • Piping GA Drawings & Piping Routing
    • Piping Isometric & Support Drawings
    • Preparing 2-D & 3-D plant model
    • Building of 3D plant model from available 2D drawings
    • Putting together the equipment list for purchase
    • Designing cause and effect diagrams
    • Preparing piping and instrument diagrams, including all stress calculations and isometrics
    • Formulating necessary start-up procedures and designing all civil and electrical diagrams
  4. Design and Drafting Services

    We have an enviable track record in providing quality designing and drafting services to our global clients for efficient plant engineering, which consists of the following -

    • Designing detailed drawings based on source data
    • Validating all drawings
    • Creating 3D parametric CAD designs
  5. 3D Modeling and Design

    Our plant 3D modeling and design services enable faster and more accurate plant modeling and design, ensuring reduced turnaround times for the related project. Our team of engineers and plant designers are well-versed in a variety of 3D design software, and provide consistent workflow integration throughout the project enterprise. Our offering for 3D modeling and design includes the following -

  6. Our 3D Modeling Services
    Service Deliverables
    Our 3D Modeling Services
    • Equipment Modeling
    • Piping Modeling
    • Pipe Rack Modeling
    • Support Modeling
    Service Deliverables
    • 3D Models in PDMS
    • General Arrangement
    • Safety Equipment Arrangement
    • Structural Elevation
    • Specifications and Datasheets
  7. As-built Documentation

    Our As-built documentation and engineering service ensures comprehensive and accurate final documentation for an as-built plant. Our experienced team of engineers is knowledgeable in a variety of commercial document management systems such as PDS, ProArc, etc., and conducts site surveys which involve taking necessary measurements, documenting markups, updating 3D models etc., based upon the client request.

  8. Piping Design

    We offer state-of-the-art piping design and engineering services to ensure optimum quantities, easy operability, ease of construction, and safety of industry plants. Our offerings for piping design and engineering include -

    • Preparation of piping specifications
    • Plot Plan development
    • Basic equipment layout
    • Equipment layout and section
    • Piping layout & sections
    • Pipe support layout & support details
    • Isometric drawings
    • Bill Of Material
    • nozzle orientation drawing
    • Valve specification
    • Erection of Piping
  9. On-site Engineering Consultation

    Our on-site plant engineering consultation service complements our clients' in-house development teams by providing consultation on varied aspects of the plant engineering lifecycle, including -

    • Consultation before permit is awarded
    • Consultation for all contractual phases
    • Due diligence
    • Project management and relocation

PDMS Project Success Stories at O2I

Our plant engineering and piping design experience spans industrial facilities both large and small. We have undertaken projects of varying complexity for our clients while leveraging our unique solutions to improve project efficiency. Some of the projects we have undertaken and successfully delivered to our global clients include -

  • TEG Package for FPSO
  • GTG Module for Fixed Process Platform
  • GTG Module for MOPU(Mobile Offshore Platform)
  • Skid Packages

Additionally, we also worked with a large coastal refinery that had an urgent requirement for listing piping instrumentation indexes, and demonstrating the physical sequences of equipment and systems. With our help, the client was able to achieve 99.9% accurate cataloguing, along with saving 50% in costs. Read the entire case study.

To know more about our PDMS capabilities, contact our representatives.

Leverage the Benefits of Outsourcing PDMS Services to O2I

At Outsource2india, our engineers and designers can not only help you optimize your plant design for better workflow, but also deliver comprehensive and accurate final deliverables while minimizing operational costs and time. We set ourselves apart from our competitors by providing the following value-added benefits -

  • A collective experience of around 10 -12 years across Sr. designers, engineers, draftsmen and managers in Plant Design Systems
  • Leveraging cutting-edge software such as PDS, PDMS, CADWORKS, BENTLEY AUTOPLANT, etc. for efficient plant designs
  • Intensive training procedures for all employees to familiarize them with the client's expected standards, including training on upgraded tools and other industrial skills
  • Leveraging Macros for modeling and drafting to reduce repetitive work, positively affecting the turnaround time
  • Extensive use of review software so as to remain up-to-date with the project progress and remove clashes whenever necessary
  • An extensive in-house PDMS database housing a variety of component catalogues & draft libraries
  • Extremely fast scalability for any process leveraging the resources available through our global delivery centers

Contact us now and learn more about how our offerings - ranging from normal piping designs to fully integrated industrial plant engineering solutions, can help you meet your organizational goals in the long run.
